Super compact amplifier with surprising performance specifications, intended for smaller PA system applications. With the use of high quality IC, the amplifier is extremely stable even where the microphone (balanced line) and speaker cables are run together for long distances. The unit will automatically shut down when severely overloaded and will restore to normal operation when the fault condition is removed. Suitable as a stand alone desk/bench unit or rack mount with optional hardware. Up to 2 units can be accommodated side by side in 1RU of rack space (44mm high). 12VDC operation makes it well suited for use in tour buses and mobile installations. Mains power adaptor is included

• 15W RMS Output
• Headphone Socket
• 1 balanced XLR and unbalanced jack mic input
• Selectable Phantom Power on Mic Input
• 1 Auxiliary Input
• Music Input on Front Panel
• 4-16Ω Standard Speaker Output
• Selectable Aux Input Sensitivity
• 12V DC operation (includes mains power supply)
• Compact 210x130x44mm
• Made in Australia

Specifications:

• Power Output
• Power: 15 watts RMS
• Distortion: < 3% @ 1kHz
• Signal to Noise Ratio: Typically > 75dB
• Frequency Response
• Mic input: 50Hz - 10kHz, -3dB
• Line input: 50Hz - 15kHz, -3dB
• Input Sensitivity:
• Mic: Rear 1.5mV balanced, Front 1.5mV unbalanced
• Line input: 500mV
• Output Connectors
• Speakers: Screw terminals
• Output impedance: 4-8Ω
• Input Connectors
• Mic : Rear 3 pin XLR balanced, Front 6.35mm jack unbalanced
• Line input: RCA stereo socket, bridged mono
• 12V DC power: 2.1mm socket
• Controls
• Mic input: Volume
• Line input: Volume
• Power: On/off switch
• Indicators: Power
• Power supply: 12V DC
• Protection: 3A DC fuse
• Weight: 0.38kg
• Dimensions: 210W x 130D x 44H mm
• Colour: Black
